OCC Recycling Paper Making Line Machine,Paper Pulping Machine For Paper Mill

Most paper mills use waste paper board as a raw material to produce paper. We are a paper machine manufacturer, and we specialize in complete sets of waste paper pulping equipment. We can offer the 120T recycling paper making line machine for paper mill.

Main Machine Of Recycling Paper Making Line

Chain Conveyor: Working Width:B=1400mm, Total Length:26m
D Type Hydrapulper: 25m3, h=10mm, C=3~5%
High Density Cleaner: Q=6500～7800l/min, C=3～5%
Mid Consistency Coarse Screen: A=1.2m2, h=2.0mm, C=3%
Light Impurity Separator
Fiber Separator: Ø880mm, h=4mm, C=2%
Reject Separator: Ø380mm, C=1.2%, Ø4mm
Mid Density Cleaner: Q=6500～7800l/min, C=2～3%
Fiber Lip Screen: A=1.2m2, S=0.2mm, C=2.5%
Low Density Cleaner: 600ml/min, C=0.7%
Mid Consistency Fine Screen: A=0.6m2, s=0.25mm, C=1.0%
Double Disc Refiner: Ø380mm, C=3~5%

Our company Leizhan is a professional manufacturer of pulp and paper making machine. We can offer the whole paper making line machine, include paper pulping making equipment and paper machine. Welcome can contact us for more details.
Email: leizhanpapermachine@gmail.com

Project Case

Kraft Liner Paper Making Line

Testline paper machine, also called kraft liner board machine is to produce testliner paper. With large capacity, lower energy consumption, superior quality and the most competitive price, our testliner paper making line enjoys the good command and admission of our customers. If you are interested in our products, welcome to our company, you can also consult via telephone or mail to us. Email: leizhanpapermachine@gmail.com

Corrugated Paper Making Line

Corrugated Paper Making Line needs Chain Conveyor, Drum Pulper, D Type Hydrapulper, Mid Consistency Pressure Screen, Double Disc Refiner, Inflow Pressure Screen, and so on. Paper pulp machine used to make waste paper turn to fine pulp for paper forming on the paper machine. Leizhan plays great emphasis on designing most suitable Corrugated packaging paper manufacturing solutions for corrugated packaging paper makers.

Cultural Paper Making Line

Cultural paper machine line: Firstly, Raw materials are conveyed by Chain Conveyor into Drum Pulper for pulping. Then, High Density Cleaner helps to remove heavy impurities. What’s more, we need to improve slurry beating degree by using Double Disc Refiner. Eventually, the waste paper turn into fine pulp after a series of screening and deslagging and it will be conveyed into Headbox for paper making.
